Operation Video of ELM-1000 Automatic Tape Dispenser
Specification of ELM-1000 Automatic Tape Dispenser
-
Acceptable Tape Width: 7-50mm
-
Available Cut Length: 20-999mm
-
Display: 3 digit LED
-
Cut Accuracy: +/-1mm
-
Counter Up or Down: Optional
-
Power supply: AC110V 60HZ, AC220V 50HZ, 18W
-
Measurement & weight: 245*137*156mm 2.4Kg
-
Application: Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Automotives, Electric & Electronics, etc.
Operation Instruction of ELM-1000 Automatic Tape Dispenser
-
Only need to stick the tape tip to the outlet, then the tape at a required length will come out automatically from the electronic tape dispensers.
-
Auto mode and manual mode is selective. In Auto mode, the carton sealing tape dispenser will cut tape automatically.
-
When a long tape is needed, keep pressing "FORWARD" key to the desired length, then press "CUT" key
-
The cutter unit cassette can be removed and replaced easily (tape jamming can be also easily fixed)
-
The cutting length is shown on the LED display, you can set the cutting length easily by "CM" and "MM" key.
-
Available tape type: PVC tape, paper tape, cloth tape, glass tape, pp tape, Kraft adhesive tape etc.
-
This wide tape dispenser for carton sealing can cut various tapes, low price and strong function make this model very popular all over the world.
Related Automatic Tape Dispensers
|
Brand
|
Model
|
Cutting length
|
Cutting width
|
|
BOJIN
|
M-1000
|
5-999mm
|
7-50mm
|
|
BOJIN
|
BJ-2000S
|
5-999mm
|
5-50mm
|
|
BOJIN
|
M-1000S
|
5-999mm
|
5-50mm
|
|
BOJIN
|
ZCUT-2
|
13-60mm
|
3-25mm
|
|
BOJIN
|
RT-3000
|
9-61mm
|
3-25mm
|
|
ELM
|
M-1000
|
20-999mm
|
7-50mm
|
|
ELM
|
MS-1100
|
30-999mm
|
7-50mm
|
|
ELM
|
TDA-080
|
40-999mm
|
13-80mm
|
|
YAESU
|
ZCUT-7
|
5-999mm
|
6-50mm
|
|
YAESU
|
ZCUT-9GR
|
5-999mm
|
6-60mm
|
|
YAESU
|
ZCUT-870
|
15-70mm
|
3-25mm
|
|
YAESU
|
ZCUT-9
|
5-999mm
|
6-60mm
|
|
YAESU
|
ZCUT-9P
|
5-999mm
|
6-60mm
|
|
ASUTECH
|
ED-100
|
5-999mm
|
7-50mm
|
